Exquisite design
Small size, small footprint, high cost performance; flexible U interface design.
Technical support
Dual guns can be customized (European standard, national standard, Japanese standard, American standard, etc.);
Optional screen language interface; docking OCPP cloud fast charging; support OEM/ODM customization
IP55 protection level
With undervoltage, overvoltage, undercurrent, overcurrent, lightning protection and other protections.
| Specifications And Descriptions | ||||||
| power | 60KW | 80kW | 120KW | 160KW | 180KW | 240KW |
| Walk-in type | 3P N PE | |||||
| Voting range | 380-400V | |||||
| frequency | 50/60Hz | |||||
| Current harmonics | ≤5% | |||||
| Power Factor | 0.99 | |||||
| power supply | TT/TN-S/TN-CS | |||||
| RCD Types | Type A | |||||
| Leakage voltage | 200-1000VICCS1200-500VICHAdeMOI | |||||
| Rated power | 6 OKW | 80kW | 120KW | 160KW | 180KW | 240KW |
| Maximum current | 120A | 150A | 200A | 250A | 280A | 300A |
| Standby consumption | ≤100W | |||||
| Stable voltage accuracy | ≤±9% | |||||
| Stable current | ≤±1% | |||||
| Number of connections | 2 | |||||
| Connection Type | CCSI/CCS2/CHAdeMo | |||||
| Peak efficiency | 96% | |||||
| Operating temperature | -25-65°℃,ower50Cderating | |||||
| Storage temperature | -40-70℃ | |||||
| humidity | 0-95%nocondensation | |||||
| altitude | ≤2000m | |||||
| EV Protocol | I9015118 | |||||
| Backend protocol | 0CPP16J | |||||
| Payment Methods | APPJS015118Pnc.passwortRAD | |||||
| Communication Type | Ethermet/wi-F/4G | |||||
| Screen | 7/15-inchLCD touchscreen | |||||
| language | EN/KC/CN | |||||
| Protection level | P55,Ik10 | |||||
| Electronic Yuan Management | Yes | |||||
| Audio | Yes | |||||
| weight | ≤600kg | |||||
| Custom functions | Tilt protection,ftood protection,freprotection,heater | |||||
| Noise level | ≤75dB | |||||
| standard | IEC61851IEC62196IEC61000 | |||||
