The heavy-duty connector can replace the socket to achieve multiple charging of one device. By replacing the charging gun, you can freely switch between CCS/CHADEMO/GBT, and charge the world with one device
Smart and convenient
Configurable OCPP function, remote control, scheduled charging, paid charging, and more functions; multiple networking methods: LAN/WIFI/4G module
IP55 protection level
Can be used outdoors, no fear of wind and rain; anti-collision level IK10, no fear of external force collision; CE certification, safe and worry-free.
| Specifications And Descriptions | |
| Input voltage | Single-Phase230V |
| Input frequency | 50-60Hz |
| Current harmonics | <5% |
| Power Factor | 0.99) |
| Output power | 7.3KW |
| Maximum output current | 16A |
| Output voltage | Single-Phase230V |
| Connector Type | Ccs,CHAdeMOJType2 |
| Peak efficiency | 96% |
| temperature | -25C-65℃℃ |
| humidity | 5%-95% |
| size | 203X300X450(mm) |
| Material | Stainless steel |
| Payment Methods | RFID/Credit/OR code |
| backup power supply | <0.1%max power |
| network | Ethernet/46 |
| Protection | P55/IK10 |
| Certification | CE,TUV,UKCA,TR25,RCM |
