| Electrical properties | |
| Rated voltage | 250VAC |
| Rated ourrent | 48A,MAX 60A |
| Insulation resistance | |
| Mechanical behavior | 1000MO(AC charging connector) |
| Durability | more than 10000 times,(non- charging state) |
| Environmental performance | |
| Ambient temperature | -65℃~ 125°C(PE cable-40℃~ 85℃) |
| Vibration | ML-STD-202 Meth.204 |
| Corrosion Resistance | ML-STD-202 Meth.101 |
| Material | |
| Shell | Thermoplastic |
| Insulator | Thermoplastic |
| Seal | rubber material |
| Insulaton flame retardant grade |
UL94-VO |
| Contact | Copper alloy with silver plating |
| Environmental performance | |
| Operating temperature | -40°F to 185°F(-40°℃ to 85℃ |
| relatve humidity | 98%at 40% |
| Degree of protection | IP55(while charging) |
| Dimensions | (L-W-H)178.8-78.7*60mm |
| Weight | 381g |
| Packaging and Shipping | |
| Mode of transport | Express/Logistics |
| Packing | olor box Velvet bag7 PE bag carton |
